The D-220 is a good sounding cassette deck from the 70ties. Comes with nice backlit meters and Dolby B noise reduction.
This unit has received the below service:
- Cleaning of flywheel from rubber residue
- Replacement of capstan belt
- Replacement of FFWD/RWD belt
- Cleaning of capstan
- Cleaning of heads
- Speed calibration
- Playback level calibration
- Record level calibration
- Demagnetisation of heads
- Full functions test
This deck comes with 6 months warranty.
Specifications
Type: 2-head, single compact cassette deck
Track System: 4-track, 2-channel stereo
Tape Speed: 4.75 cm/s
Heads: 1 x record/playback, 1 x erase
Motor: electronically controlled DC
Tape Type: type I, CrO2
Noise Reduction: B
Frequency Response: 30Hz to 14.5kHz (CrO2 tape)
Signal to Noise Ratio: 58dB (dolby B)
Wow and Flutter: 0.09%
Total Harmonic Distortion: 1.8%
Input: 60mV (line), 0.35mV (mic)
Output: 0.5V (line)
Dimensions: 390 x 143 x 254mm
Weight: 4.1kg
Year: 1977
